VP-25Wx series OS: V1.1.0.1 Update Release |
|
|
|
|
|
 |
|
|
|
|
|
This update fixes a major bug which OS hangs due to CPU over-loading when some programs (example: NAPOPC_CE and InduSoft) run over 8 hours; And adds two convenient functions:(1) the prefix name of multi-serial modules (I-811xW or I-814xW) can be "COMx" or "MSAx/MSBx". (2) The front side Function Key F1~F6 can be defined as the hotkey for specific application programs. |
|
|
|
|
|
Latest Software Version
OS image: Ver 1.1.0.1 |
|
|
|
|
|
New Features: |
|
|
- The prefix name of multi-serial modules (I-811xW or I-814xW) can be ¡§COMx¡¨ or "MSAx/MSBx".
- ViewPAC utility: supported by V2.0.1.5 or later
- The prefix name only be ¡§MSAx/MSBx¡¨ in the previous OS versions
- Execute specific application programs respectively by Function key F1~F6
- ViewPAC Utility: supported by V2.0.1.5 or later.
- Show the CPU frequency to system properties "Processor".
|
|
|
|
|
|
Bug Fixes: |
|
|
- OS hangs when some programs (example: NAPOPC_CE or InduSoft) run over 8 hours. In that case, the kernel bug (sleep function in source code of RTC.c) causes CPU over-loading and makes the OS out of work.
- Application program hangs after system booting if it uses any multi-serial modules (I-811xW or I-814xW). The bug is due to wrong boot sequence. The multi-serial driver should be loaded before executing auto-run programs set by WinPAC/ViewPAC utility. If an AP launches the multi-serial driver but the driver does not be loaded yet, it hangs. This update puts multi-serial driver to higher boot sequence.
- Sometimes application programs don¡¦t be executed automatically after system booting. The bug is due to wrong boot sequence. The disk drivers (System_Disk and Micro_SD) should be loaded before executing auto-run programs set by the WinPAC/ViewPAC utility. If the disk drivers are not ready, OS will be not able to find the application programs and execute them. This update puts disk drivers to higher boot sequence.
|
|
|
|
|
|
Improvements: |
|
|
|
|
|
|
|
|
Modifications: |
|
|
|
|
|
|
|
|
Eboot: Ver 1.0.1.1 |
|
|
|
|
|
ViewPAC Utility: Ver 2.0.1.5 |
|
|
more information... |
|
|
|
|
|
More update information: |
|
|
Refer to... |
|
|
|
|
|
For details please refer to ViewPAC-8000 download center http://www.icpdas.com/products/PAC/viewpac/download/viewpac/download_os_images.htm
Release Note http://ftp.icpdas.com/pub/cd/winpac/napdos/vp-2000_ce50/os_image/vp-25w1/viewpac-25wx_os_release_note_v1.1.0.1_eng.pdf |
|
|
|
|
|
|
 |
