WP-8x4x series important update |
|
|
|
|
|
|
|
|
|
|
|
This update fixes major bugs to improve the OS stability and supports multi-serial modules.
Please update your WinPAC right now. |
|
|
|
|
|
Latest Software Version
OS image: Ver 1.3.0.4 |
|
|
New Features |
|
|
- Supports Multi-serial module ( i-8112iW,i-8114W, i-8114iW,i-8142iW, i-8144iW)
- To configure the modules, you have to update WinPAC Utility to Ver 2.0.0.6.
- Supports WP-8141.
Since version 1.3.0.4, the OS can support all of WP-8x41 series.
|
|
|
|
|
|
Bug Fixes |
|
|
- Some modules (i-8017HW, i-8094H) plugged in Slot0~Slot3 make communication error to COM2,COM3 and COM4.
- CPU loading becomes 50% even there is no program running. It should be less than 2%.
- Can not run programs for more than 3 days.
- Can not perform on-line debug on VS.Net 2005.
- SQL command "sqlCmd.ExecuteResultSet(ResultSetOptions.Scrollable)" causes an error exception. SQL CE 3.5 (3.5.5692.0) been recovered to SQL CE 3.5 (3.5.5386.0)
- Interrupt function of I/O module does not work.
The interrupt number is redefined in OS version 1.3.0.4. To make interrupt function of I/O modules work correctly, WinPACSDK.dll must be updated to ver 1.0.7.9 or later. Interrupt related I/O modules include i-8048W, i-8092F, i-8094F, i-8094H.
|
|
|
|
|
|
Modifications |
|
|
- Set the running LED (on the front panel) always On after the system booting.
Before, the LED is keep at blank and sometimes flashing.
|
|
|
|
|
|
Eboot: Ver 1.0.5.6 |
|
|
New Features |
|
|
- Eboot can be updated to WP-814x/WP-844x/WP-884x controller
|
|
|
|
|
|
Bug Fixes |
|
|
- Date of the Eboot cannot be saved to EEPROM. This makes the information shown on WinPAC Utility is always "FFFFFF".
|
|
|
|
|
|
WinPAC Utility: Ver 2.0.0.6 |
|
|
New Features |
|
|
- Adds "Multi-serial port wizard" to configure multi-serial modules.
- Shows the battery capacity of the Dual-Battery Backup SRAM on the backplane.
- Shows Module type (I-8K or I-87K) on System Information
|
|
|
|
|
|
More information...
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/system_disk/tools/winpac_utility/releasenotes.htm |
|
|
|
|
|
More Information about WinPACSDK.DLL: Ver 1.0.7.9...
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/sdk/winpacsdk/ |
|
|
|
|
|
More information about WinConSDK.DLL: Ver 2.2.0.11...
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/sdk/winconsdk/winconsdk_history_ver2.2.0.11.htm |
|
|
|
|
|
For details please refer to WinPAC-8000 download center
http://www.icpdas.com/products/PAC/winpac/download/winpac_8000/download_os_images.htm |
|
|
|
|
|
|
|
|
|
|
