Input |
Voltage range |
100-240 VAC or 127 ~ 370 VDC |
Frequency |
50/60 Hz |
Input current |
0.2 A(rms) for 100 VAC |
Leakage current (max.) |
0.25 mA/240 VAC |
Inrush current (max.) |
50 A @ 230 VAC |
Output |
Voltage |
24 VDC |
Output current |
0.25 A |
Over voltage protection |
Yes (clamp by Zener diode). |
Over load |
>110% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed |
Temperature coefficient |
0.03%/°C (0 ~ 50°C) |
Efficiency |
82% (Efficiency is measured at 230 VAC) |
Setup, Rise, Hold up time |
1000ms, 50ms, 12ms at full load |
Line regulation |
0.5% max (Line regulation is measured from low line to high line at rated load) |
Load regulation |
2% (Load regulation is measured from 0% to 100% rated load) |
General |
MTBF |
50,000 hours min at full load at 25°C ambient. |
Environmental |
Operating Temperature |
0°C ~ +40°C |
Storage Temperature |
-20°C ~ +85°C |
Humidity |
20~ 90% HR, Non-condensing |
Standards |
Safety standards |
EN60950-1 approved |
EMC EMISSION |
Compliance to EN55022, EN61000-3-2,3, FCC Part15 class B |
