Model |
|
|
|
I/O Type |
Digital Input & Output |
Digital Input & Relay Output |
Analog Input |
| DI |
Channel |
8 |
6 |
- |
| Type |
Dry, Wet |
Dry, Wet |
- |
| Sink/Source |
Sink, Source |
Sink, Source |
- |
| DO |
Channel |
8 |
- |
- |
| Type |
Open Collector |
- |
- |
| Sink/Source |
Sink |
- |
- |
| Relay Output |
Channel |
- |
6 |
- |
| Relay |
- |
Power Relay |
- |
| Type |
- |
Form A (SPST-NO) |
- |
| Max. Load Current |
- |
5.0A/channel |
- |
| AI |
Channel |
- |
- |
- |
| Voltage & Current Input |
- |
- |
±15 mV, ±50 mV, ±100 mV, ±150 mV, ±500 mV, ±1 V, ±2.5 V, ±5 V, ±10 V
±20 mA, 0 ~ +20 mA, +4 ~ +20 mA
|
| Sensor Input |
- |
- |
Thermocouple : J, K, T, E, R, S, B, N, C, L, M and LDIN43710 |
|
