I-87120 (I-87KCAN)
1 Port Programmable CAN bus communication module
|
|
|
|
|
|
|
|
| |
|
|
| |
CAN (Controller
Area Network) is a serial bus control protocol especially suited
to constrnct intelligent industry devices networks and build smart
automatic control systems. It is popularly applied in the industrial
automation, building automation, vehicle, marine, and embedded
control network. In order to expand the CAN functions of ICPDAS
products, I-87120 module is developed for this purpose. It is
a kind of module, and need to be plugged into a host unit,
such as I-8000 series MCU (Main Control Unit), |
|
| |
WinCon-8000
and LinCon-8000. I-87120 give a way to connect these ICPDAS host
unit with CAN network. Owing to the features of I-8000 series MCU, WinCon-8000, WinPAC-8000 and LinCon-8000, these host units can be arranged
to be a CAN converter, CAN slave device and CAN master device
in a CAN network. The righr-hand-side figure shows the application architecture
for I-87120 modules. |
|
|
|
| |
|
| |
|
| |
DeviceNet, CANopen,
CAN J1939, SDS (System Wide Network) protocol application
CAN bus communication
application.
Industry automation
Industrial Machinery
Building Automation
Food & Beverage
Semiconductor Fabrication
Control system
|
| |
|
|
|
| |
|
|
| |
|
|
| |
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
Common
Features:
- One CAN port expansion for I-8000 series
MCU (main control unit), WinCon-8000, WinPAC-8000 and LinCon-8000
- 4096 records CAN message receive-buffer
size
- 4096 records buffer size for the command
from I-8000 series MCU/ WinCon-8000/WinPAC-8000/LinCon-8000 to I-87120
- Provide C/C++ function libraries to
send and receive CAN messages
- Demos and utility are provided
- 3 indication LEDs (Rx, Tx and Err LEDs)
CAN Port Features:
- Support user-defined baud
- 2500 Vrms isolation
- Baud : 5Kbps, 10Kbps, 20Kbps, 25Kbps,
50Kbps, 100Kbps, 125Kbps, 200Kbps, 250Kbps, 500Kbps, 800Kbps,
1Mbps
|
| |
|
|
|
| |
|
| |
|
| |
Hardware |
CPU |
80186, 80 MHz or compatible |
SRAM/Flash/EEPROM |
512 KB / 512 KB / 2 KB |
RTC (Real Time Clock) |
Yes |
CAN Interface |
Controller |
NXP SJA1000T with 16 MHz clock |
Transceiver |
NXP 82C250 |
Channel number |
1 |
Connector |
5-pin screwed terminal block (CAN_L, CAN_SHLD, CAN_H, N/A for others) |
Baud Rate (bps) |
10 k, 20 k, 50 k, 125 k, 250 k, 500 k, 800 k, 1 M (allow user-defined baud rate) |
Transmission Distance (m) |
Depend on baud rate (for example, max. 1000 m at 50 kbps ) |
Isolation |
3000 VDC for DC-to-DC, 2500 Vrms for photo-couple |
Terminator Resistor |
Jumper for 120 £[ terminator resistor |
Specification |
ISO-11898-2, CAN 2.0A and CAN 2.0B |
LED |
Round LED |
Tx/Rx LED, ERR LED |
Software |
Driver |
For I-8000/IP-8000/ViewPAC/WinPAC/LinPAC/ XPAC |
Library |
TC/BC, GCC, VB.Net 2003, C#.Net 2003, VB.Net 2005, C#.Net 2005, eVC++ 4.0 |
Power |
Power supply |
Unregulated +10 ~ +30 VDC |
Power Consumption |
2 W |
Mechanism |
Dimensions |
31mm x 91mm x 115mm (W x L x H) |
Environment |
Operating Temp. |
-25 ~ 75 ¢J |
Storage Temp. |
-30 ~ 80 ¢J |
Humidity |
10 ~ 90% RH, non-condensing |
|
| |
|
|
|
| |
|
| |
|
| |
Development Toolkit for I-8000/WinCon/LinCon/WinPAC
I-87120 (I-87KCAN) don't support any ISaGRAF series main control unit
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
I-87120-G (I-87KCAN) |
Module with one programmable CAN port, I-8000/IP-8000/ViewPAC/WinPAC/LinPAC/ XPAC library, 80186 80 MHz CPU, 512 KB Flash and SRAM, 120 £[ terminal resister selected by jumper. |
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
Libary & Demo for I-87120 user-defined firmware |
Document |
Version |
Download |
Size |
Update |
Remarks |
Library |
1.10 |
|
66.6KB |
May-20-2008 |
|
Demo |
1.03 |
|
1.31MB |
May-20-2008 |
|
|
|
| |
|
|
| |
Libary & Demo for I-8000 Series |
Document |
Version |
Download |
Size |
Update |
Remarks |
Library |
1.03 |
|
3.5KB |
Aug-06-2006 |
|
Demo |
1.00 |
|
0.16MB |
Aug-06-2006 |
|
|
|
| |
|
|
| |
Libary & Demo for WinCon-8000 Series |
Document |
Version |
Download |
Size |
Update |
Remarks |
Library |
1.10 |
|
5.04KB |
May-20-2008 |
|
Demo |
1.10 |
|
229KB |
May-20-2008 |
|
|
|
| |
|
|
| |
Libary & Demo for WinPAC-8000 Series |
Document |
Version |
Download |
Size |
Update |
Remarks |
Library |
1.10 |
|
5.15KB |
May-20-2008 |
|
Demo |
1.10 |
|
234KB |
May-20-2008 |
|
|
|
| |
|
|
| |
Libary & Demo for LinCon-8000 Series
|
Document |
Version |
Download |
Size |
Update |
Remarks |
Library |
1.03 |
|
14.5KB |
Aug-06-2006 |
|
Demo |
1.00 |
|
0.12MB |
Aug-06-2006 |
|
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
